Product highlights

  • Vsync provides excellent patient–ventilator synchrony, even in the presence of significant leak.
  • TiControl™ lets you set min and max limits on either side of the patient’s ideal inspiratory time to encourage spontaneous breath.
  • Trigger and cycle helps you optimise settings according to the patient’s condition, using five trigger and cycle sensitivity levels.
  • QuickNav for low-touch therapy adjustment. By simply double-clicking the home button on the device, you can toggle between the Settings and Monitoring screens to change and check settings quickly and easily.
  • Climate Control Auto for automatic humidification. When used with a HumidAir™ heated humidifier and ClimateLineAir™ heated tube, Lumis delivers humidification automatically – no settings to change and no complicated menus to navigate.
  • Ramp and Ramp Down for extra comfort. Lumis offers both Ramp and Ramp Down features to help patients ease into and out of each therapy session.
  • ResScan software for advanced clinical insights. ResScan enables you to download your patients’ therapy data, change ventilator settings, and gain insight into their therapy progress across a number of metrics (including AHI, leak and pressure). High-resolution data (at 25 Hz) is also available for breath-by-breath analysis and even greater insight.

Track your sleep with myAir

Available for all Lumis 100 users, the ResMed myAir™ app and web program lets you see how you're doing on therapy every day and receive personalized tips.

Download is subject to availability of application approval in each country.

icon-eyebrow-documents-black

Documents center

icon-eyebrow-question-mark-black

Frequently asked questions

How do I adjust the comfort features – Humidity Level and Ramp Time – on my Lumis 100 VPAP?

Your Lumis 100 VPAP machine has been set up for your needs by your medical equipment supplier – the store where you picked up your equipment. But you may want to make small adjustments based on your comfort needs. Here are some tips on how to adjust the comfort settings.

How to access your comfort settings on the Lumis 100 VPAP:

On your Lumis 100 VPAP machine, rotate the dial to highlight My Options and press the dial to see your current settings. From here, you can personalize your options.

Humidity Level

The humidifier moistens the air and is designed to make your therapy more comfortable. If you're getting a dry nose or mouth, turn up the humidity. If you're getting any moisture in your mask, turn down the humidity.

You can manually set the Humidity Level to Off or between 1 and 8, where 1 is the lowest humidity setting and 8 is the highest humidity setting.

How to adjust humidity:

  1. In My Options, turn the dial to highlight Humidity Level and then press the dial.
  2. Turn the dial to adjust the humidity level and press the dial to save the change.

If you continue to get a dry nose or mouth, or moisture in your mask, consider using ClimateLineAir™ heated air tubing. ClimateLineAir together with Climate Control delivers more comfortable therapy.

Ramp Time

Ramp Time is the period during which the pressure increases from a low start airflow pressure to your prescribed treatment pressure. You can set your Ramp Time to Off, 5 to 45 minutes.

How to adjust Ramp Time:

  1. In My Options, turn the dial to highlight Ramp Time and then press the dial.
  2. Turn the dial to adjust the ramp time to your preferred setting and press the dial to save the change.

Need more help with your comfort settings? Your medical equipment store can help make any other necessary adjustments.

I’m having issues with my equipment and need help. Who should I contact?

The CPAP equipment provider – the store where you picked up your machine – is responsible for providing you with ongoing clinical support, including answering any questions and helping you resolve any issues that you may be experiencing with your Lumis 100 VPAP machine or settings.

Not sure who your CPAP equipment provider is? We can help, fill out our Contact Us form or simply use our Chat Bot.

How do I clean my Lumis 100 VPAP and how often?

You should clean your machine weekly.

How to clean your Lumis 100 VPAP

Time it takes: 5 minutes

Weekly step-by-step cleaning tips:

  1. Unplug the machine.
  2. Wash the water tub and air tubing in warm water using mild detergent. Do not wash in a dishwasher or washing machine.
  3. Rinse the water tub and air tubing thoroughly and allow to dry out of direct sunlight and/or heat.
  4. Wipe the exterior of the device with a dry cloth or towel.

Can I use an ozone device to clean my ResMed device?

ResMed has observed that prolonged and repeated use of an ozone device may eventually cause internal damage to a ResMed machine, leading to an increase in motor noise. The ResMed limited warranty excludes damage to ResMed machines caused by use of ozone devices.

How often should I replace the parts to my Lumis 100 VPAP and can I sign up for a replacement program?

It's important to take regular care of your therapy supplies – especially your machine supplies, which can be affected by dirt and general wear. You should regularly check the water tub, air tubing and the air filter for any wear or damage.

Here are some replacement tips for your Lumis 100 VPAP machine:

  1. Water tub:
    • Replace if it begins leaking or has become cracked, cloudy or pitted.
    • Replace if the seal is cracked or torn.
    • Remove any white powder deposits using a solution of one-part household vinegar to 10 parts water.
  2. Air tubing:
    • Replace if there are any holes, tears or cracks.
  3. Air filter:
    • Replace if it air filters have become dirty or clogged, which can expose you to airborne particles, mold and bacteria.
    • Replacement is recommended at twice per month.

Your medical equipment provider may have a replacement supply (resupply) program that you can enroll in to get new parts on a consistent schedule. You should also check with your insurance to see what replacement parts are covered under your plan and how often you can replace them.

Which ResMed masks are compatible with Lumis 100 VPAP?

While ResMed masks are designed to be compatible with most ResMed machines, it is best to confirm compatibility for your specific mask to determine the correct mask setting for your machine.

Here's a list of compatible masks:

Full face masks:

Nasal/nasal pillow masks:

Click here for the most up-to-date list of compatible masks.
